4,547 CFM UNIKEM DUST COLLECTOR - MODEL 1500-36-156-2000 (#9843)
Model 1500-36-156-2000 features sealed pleated PTFE coated fabric filter technology to deliver high efficiency clean air and long life.
700 sq. ft. of Media Area
Rating: 454-4,547 CFM @ 12.79 WC
Enhanced performance features with ease of installation and service make the UniKem model 1500-36-156-2000 the ultimate choice for cleaning the work environment of irritating dust and fumes. • Designed for non-hazardous dusts or full compliance with NFPA 68 and relative codes according to your process.
Unikem Filters Technology
• UniKem filters have high capacity due to the pleated filter and inner cone pulse venturi. • The inner cone provides uniform dispersion of back-pulsed air and opens up more useable space for airflow in the dust collector. • Multiple filter media options and spacings are available to best suit your specific application and dust. • All UniKem filter media offerings deliver a minimum of 99.9% separation efficiency down to 0.5 micron by weight.
UniKems’ collector module is constructed of 4-gauge (3/16”) 304L stainless steel. • Davited door, explosion vent frame, hopper, inlet, and shell are all 304L stainless steel. • Most other dust collectors on the market are only 12 (5/64”) gauge or thinner. • Hoppers have standard 8” discharge, unless otherwise specified herein. Rotary airlock valve is optional.
PDF Cut sheet available
General Application Specifications
UniKem Model: 1500-36-156-2000
Dust Type: Non-hazardous
Reference: General Process Exhaust
Estimated Height: 214 inches
Rating: 454 - 4,547 cfm @12.79” WC
A/C Ratio: .65 - 6.49:1
Media Area: 700 ft²
Operating Temperature: Ambient Fahrenheit
Dew Point: Ambient Fahrenheit
Application/Process: Process exhaust
|Media Area||700 ft²|
|CFM Rating||454-4,547 CFM @ 12.79" WC|
